TVS Raider 125 Specifications
TVS Raider 125 have 7 variants ranging from ₹ 98,122 to ₹ 1.15 Lakh. Raider 125 is powered by a 1 cylinder, 124.8 cc, Air and oil cooled single cylinder SI.
It is able to produce 11.2 Nm @ 6000 rpm torque and 11.69 bhp @ 7500 rpm power.
Keep scrolling to explore detailed configuration, features and technical specs of Raider 125.
TVS Raider 125 Safety Features
This Commuter bike comes loaded with AHO (Automatic Headlight On), Hazard Warning Indicator, Hazard Warning Switch, Side Stand Alarm, Pass Light, Pillion Grabrail, Halogen Turn Signal from safety point of view.TVS Raider 125 Weight & Height
The seat height of TVS Raider 125 is 780 mm and the kerb weight is 123 kg. In other dimensions Raider 125 has 2070 mm Length, 785 mm Width, 1028 mm Height, 1326 mm Wheelbase, 180 mm Ground Clearance, 10 Litres Fuel Tank Capacity , 1 Litres Engine Oil Capacity, Commuter Body Type.Comfort in TVS Raider 125
From Comfort perspective, Raider 125 have Average Speed Indicator, Low Battery Indicator, Pillion Footrest, Service Reminder Indicator, Under Seat Storage, Digital Console Type, Distance to Empty Indicator, Digital Instrument Console, Single Seat Style, Side Stand Indicator, Self Start Start Type, USB Charger Port.TVS Raider 125 Body
TVS Raider 125 has Telescopic suspensions with 80/100 - 17 front tyre and Monoshock& 5-step adj& Gas charged suspensions with 100/90 - 17 rear tyre. It comes with a Single cradle tubular frame frame and .TVS Raider 125 Alternatives
Main Competitors of Raider 125 bike are Hero Xtreme 125R, TVS Apache RTR 160, Hero Super Splendor Xtec, Honda SP 160, Bajaj Pulsar 150 Single Disc, Keeway SR125, Bajaj Pulsar 125, Honda SP 125, Honda Shine, Hero Splendor Plus.TVS Raider 125 Latest Price
Raider 125 is available in India starting from ₹ 98,122 with it's least expensive variant being Drum. Most expensive variant of Raider 125 is SmartXonnect priced at ₹ 1.15 Lakh.Keep scrolling to explore detailed configuration, features and technical specs of Raider 125.
| Key Highlights | TVS Raider 125 |
|---|---|
| Engine Capacity | 124.8 cc |
| Power | 11.69 bhp @ 7500 rpm |
| Seat Height | 780 mm |
| Weight | 123 kg |
Explore more on TVS Raider 125
Don't miss out on Latest Offers!
Key Specifications of Raider 125
| Key | Specs Value |
|---|---|
| Number of gears | 5 Speed |
| Seat Height | 780 mm |
| Mileage | 56.7 kmpl |
| Fuel Tank Capacity | 10 Litres |
| Kerb Weight | 123 kg |
Ad
Detailed Specifications of TVS Raider 125
Select Variants
Brakes, Suspension & Tyres
| Braking System | SBT |
| Calliper Type | Fixed |
| Front Disc Size | 130 |
| Front Suspension Preload Adjuster | No |
| Front Tyre Pressure (Rider & Pillion) | 25 |
| Front Tyre Pressure (Rider) | 25 |
| Front Wheel Size | 17 |
| Rear Suspension Preload Adjuster | Yes |
| Rear Tyre Pressure (Rider & Pillion) | 32 |
| Rear Tyre Pressure (Rider) | 28 |
| Rear Wheel Size | 17 |
| Wheel Type | Alloy |
| Front Suspension | Telescopic |
| Rear Suspension | Monoshock& 5-step adj& Gas charged |
| Front Tyre Size | 80/100 - 17 |
| Rear Tyre Size | 100/90 - 17 |
| Front Type | Drum |
| Rear Disc/Drum Size | 130 mm |
| Rear Type | Drum |
| Tubeless Tyres | Yes |
| Tyre Size Spare | No |
Comfort & Convenience
| Average Speed Indicator | Yes |
| Call/SMS Alerts | No |
| Front Storage Box | No |
| Geo Fencing | No |
| Low Battery Indicator | Yes |
| Low Oil Indicator | No |
| Pillion Backrest | No |
| Pillion Footrest | Yes |
| Service Reminder Indicator | Yes |
| Under Seat Storage | Yes |
| GPS & Navigation | No |
| Console Type | Digital |
| Distance to Empty Indicator | Yes |
| Engine Kill Switch | No |
| Instrument Console | Digital |
| Seat Style | Single |
| Side Stand Indicator | Yes |
| Start Type | Self Start |
| USB Charger Port | Yes |
Engine & Transmission
| Gear Shifting Pattern | 1 Down 4 Up |
| Ignition | CDI |
| Spark Plugs | Yes |
| Engine Capacity | 124.8 cc |
| Engine Type | Air and oil cooled single cylinder SI |
| No. of Cylinders | 1 |
| No. of valves per cylinder | 3 |
| Transmission Type | Manual |
| Battery Capacity | 124 kwh |
| Battery Type | MF battery |
| Bore x Stroke | 53.5 mm x 55.5 mm |
| Charging Socket | Yes |
| Configuration | Single Cylinder |
| Cooling type | Air/Oil Cooled |
| Fuelling | EcoThrust Fuel Injection |
| Max Power | 11.69 bhp @ 7500 rpm |
| Max Torque | 11.2 Nm @ 6000 rpm |
| Mileage (Claimed) | 56.7 kmpl |
| Number of Gears | 5 Speed |
Instrumentation
| Riding Modes Switch | No |
| Touch Screen Display | No |
| Fuel level guage | Yes |
| Gear Indicator | Yes |
| Tachometer | Digital |
| Speedometer | Digital |
| Odometer | Digital |
Safety
| AHO (Automatic Headlight On) | Yes |
| Hazard Warning Indicator | Yes |
| Hazard Warning Switch | Yes |
| Radial Tyres | No |
| Side Stand Alarm | Yes |
| Pass Light | Yes |
| Pillion Grabrail | Yes |
| Turn Signal | Halogen |
| ABS - Anti-lock braking system | No |
| Power Modes | No |
| Traction Control System | No |
Dimensions & Capacity
| Length | 2070 mm |
| Width | 785 mm |
| Height | 1028 mm |
| Wheelbase | 1326 mm |
| Ground Clearance | 180 mm |
| Fuel Tank Capacity | 10 Litres |
| Engine Oil Capacity | 1 Litres |
| Body Type | Commuter |
| Seat Height | 780 mm |
| Unladden/Kerb Weight | 123 kg |
Exterior
| Daytime Running Lights | Yes |
| LED headlight | Yes |
Warranty
| Basic Warranty | 5 Years or 60000 kms |
Body & Suspension
| Frame Type | Single cradle tubular frame |
Entertainment & Communication
| MID (Multi Info Display) | Yes |
