TVS XL 100 Specifications
TVS XL 100 have 4 variants ranging from ₹ 58,228 to ₹ 77,156. XL 100 is powered by a 1 cylinder, 99.7 cc, 4 stroke Single Cylinder.
It is able to produce 6.5 Nm @ 3500 rpm torque and 4.3 bhp @ 6000 rpm power.
Keep scrolling to explore detailed configuration, features and technical specs of XL 100.
TVS XL 100 Safety Features
This scooter comes loaded with Halogen Turn Signal, Pillion Grabrail, Hazard Warning Indicator, SBT Brake Assist, Automatic Slipper Clutch from safety point of view.TVS XL 100 Weight & Height
The seat height of TVS XL 100 is 787 mm and the kerb weight is 88 kg. In other dimensions XL 100 has 1895 mm Length, 670 mm Width, 1077 mm Height, 1228 mm Wheelbase, 145 mm Ground Clearance, 4 Litres Fuel Tank Capacity , 0.8 Litres Engine Oil Capacity, Moped Body Type.Comfort in TVS XL 100
From Comfort perspective, XL 100 have Pillion Footrest, Low Oil Indicator, Analogue Instrument Console, Analogue Console Type, Engine Kill Switch, Comfortable long single seat Seat Style, Kick Start Start Type, USB Charger Port.TVS XL 100 Body
TVS XL 100 has Telescopic Hydraulic spring type suspensions with 2.50 - 16 41L front tyre and Swing arm with Hydraulic Shocks suspensions with 2.50 - 16 41L rear tyre. It comes with a Welded Tubular step through construction frame and Spoke.TVS XL 100 Alternatives
Main Competitors of XL 100 scooter are TVS Jupiter, Suzuki Access 125, Honda Activa, Honda Dio, TVS Jupiter 125, TVS Scooty Zest 110, Honda Activa 125, TVS NTORQ 125, Hero Pleasure Plus, Yamaha RayZR 125 Fi-Hybrid.TVS XL 100 Latest Price
XL 100 is available in India starting from ₹ 58,228 with it's least expensive variant being Heavy Duty. Most expensive variant of XL 100 is HeavyDuty i-Touchstart Win Edition priced at ₹ 77,156.Keep scrolling to explore detailed configuration, features and technical specs of XL 100.
Key Highlights | TVS XL 100 |
---|---|
Engine Capacity | 99.7 cc |
Power | 4.3 bhp @ 6000 rpm |
Seat Height | 787 mm |
Weight | 88 kg |
Explore more on TVS XL 100

Don't miss out on Latest Offers!
Key Specifications of XL 100
Key | Specs Value |
---|---|
Seat Height | 787 mm |
Mileage | 53.5 kmpl |
Fuel Tank Capacity | 4 Litres |
Kerb Weight | 88 kg |
Front Brake Type | Drum |
Ad
Detailed Specifications of TVS XL 100
Select Variants
Brakes, Suspension & Tyres
Rear Tyre Pressure (Rider) | 35 |
Rear Wheel Size | 16 |
Front Disc Size | 110 |
Front Suspension Preload Adjuster | No |
Front Tyre Pressure (Rider & Pillion) | 25 |
Rear Suspension Preload Adjuster | No |
Rear Tyre Pressure (Rider & Pillion) | 40 |
Braking System | SBT |
Wheel Type | Spoke |
Calliper Type | No |
Front Tyre Pressure (Rider) | 25 |
Front Wheel Size | 16 |
Front Suspension | Telescopic Hydraulic spring type |
Rear Suspension | Swing arm with Hydraulic Shocks |
Front Tyre Size | 2.50 - 16 41L |
Rear Tyre Size | 2.50 - 16 41L |
Tubeless Tyres | No |
Front Type | Drum |
Rear Disc/Drum Size | 110 mm |
Rear Type | Drum |
Safety
AHO (Automatic Headlight On) | No |
Hazard Warning Switch | No |
Radial Tyres | No |
Turn Signal | Halogen |
Pass Light | No |
Pillion Grabrail | Yes |
Hazard Warning Indicator | Yes |
Brake Assist | SBT |
Slipper Clutch | Automatic |
Traction Control System | No |
ABS - Anti-lock braking system | No |
Power Modes | No |
Comfort & Convenience
Geo Fencing | No |
Call/SMS Alerts | No |
Low Battery Indicator | No |
Pillion Footrest | Yes |
Average Speed Indicator | No |
Riding Modes | No |
Low Oil Indicator | Yes |
Front Storage Box | No |
Service Reminder Indicator | No |
Under Seat Storage | No |
Pillion Backrest | No |
GPS & Navigation | No |
Side Stand Indicator | No |
Instrument Console | Analogue |
Console Type | Analogue |
Engine Kill Switch | Yes |
Seat Style | Comfortable long single seat |
Start Type | Kick Start |
USB Charger Port | Yes |
Luggage Space | No |
Distance to Empty Indicator | No |
Instrumentation
Touch Screen Display | No |
Riding Modes Switch | No |
Fuel level guage | Analog |
Gear Indicator | No |
Tachometer | No |
Speedometer | Analogue |
Odometer | Analogue |
Engine & Transmission
Gear Shifting Pattern | Automatic |
Ignition | CDI |
Spark Plugs | 1 Per Cylinder |
Engine Capacity | 99.7 cc |
Engine Type | 4 stroke Single Cylinder |
No. of Cylinders | 1 |
No. of valves per cylinder | 2 |
Transmission Type | Automatic |
Battery Capacity | 0.036 kwh |
Top Speed | 58 kmph |
Max Power | 4.3 bhp @ 6000 rpm |
Fuelling | Fuel Injection |
Charging Socket | Yes |
Cooling type | Air Cooled |
Max Torque | 6.5 Nm @ 3500 rpm |
Mileage (Claimed) | 53.5 kmpl |
Bore x Stroke | 51 mm x 48.8 mm |
Configuration | 10.3:1 |
Dimensions & Capacity
Length | 1895 mm |
Width | 670 mm |
Height | 1077 mm |
Wheelbase | 1228 mm |
Ground Clearance | 145 mm |
Fuel Tank Capacity | 4 Litres |
Engine Oil Capacity | 0.8 Litres |
Body Type | Moped |
Seat Height | 787 mm |
Unladden/Kerb Weight | 88 kg |
Exterior
Daytime Running Lights | Yes |
LED headlight | No |
Warranty
Basic Warranty | 3 Years/36000 Kms |
Entertainment & Communication
MID (Multi Info Display) | No |
Body & Suspension
Frame Type | Welded Tubular step through construction |
