Harley-Davidson Breakout 117 Specifications
Breakout 117 is available in India at a price tag of ₹ 35.20 Lakh. Breakout 117 is powered by a 1923 cc, Milwaukee-Eight 117.
It is able to produce 168 Nm @ 3500 rpm torque and 101.9 bhp @ 5020 rpm power.
Keep scrolling to explore detailed configuration, features and technical specs of Breakout 117.
Harley-Davidson Breakout 117 Safety Features
This Cruiser bike comes loaded with AHO (Automatic Headlight On), Hazard Warning Indicator, Hazard Warning Switch, Radial Tyres, Pass Light, Pillion Grabrail, LED Turn Signal, Dual Channel ABS ABS - Anti-lock braking system , Dual Channel ABS Brake Assist, Assist And Slipper Clutch Slipper Clutch, Traction Control System from safety point of view.Harley-Davidson Breakout 117 Weight & Height
The seat height of Harley-Davidson Breakout 117 is 665 mm and the kerb weight is 296 kg. In other dimensions Breakout 117 has 2370 mm Length, 950 mm Width, 1085 mm Height, 1695 mm Wheelbase, 115 mm Ground Clearance, 18.9 Litres Fuel Tank Capacity , 4.7 Litres Engine Oil Capacity.Comfort in Harley-Davidson Breakout 117
From Comfort perspective, Breakout 117 have Low Battery Indicator, Low Oil Indicator, Pillion Footrest, Service Reminder Indicator, Distance to Empty Indicator, Engine Kill Switch, Side Stand Indicator, Self Start Start Type, USB Charger Port.Harley-Davidson Breakout 117 Body
Harley-Davidson Breakout 117 has Dual-bendinvalv4mtelescopiwitaluminufortriplclampsduaratspring suspensions with 130/60 - B21 front tyre and Hidden& free piston& coil-over moNoshock; 43mm stroke; toolless hydraulic preload adjustment suspensions with 240/40 - R18 rear tyre. It comes with a Mild Steel& Tubular Frame frame and Alloy.Harley-Davidson Breakout 117 Alternatives
Main Competitors of Breakout 117 bike are Ducati Panigale V4, Indian Motorcycle Springfield, Kawasaki Ninja H2 SX, BMW K 1600, Indian Motorcycle Springfield Dark Horse, Kawasaki Ninja H2 SX SE, Harley-Davidson Fat Boy 114, Indian Motorcycle Chieftain Dark Horse, Harley-Davidson Heritage Classic BS6, Indian Motorcycle Chieftain Limited.Harley-Davidson Breakout 117 Latest Price
Breakout 117 is available in India starting from ₹ 35.20 Lakh with it's least expensive variant being STD. Most expensive variant of Breakout 117 is STD priced at ₹ 35.20 Lakh.Keep scrolling to explore detailed configuration, features and technical specs of Breakout 117.
Key Highlights | Harley-Davidson Breakout 117 |
---|---|
Engine Capacity | 1923 cc |
Power | 101.9 bhp @ 5020 rpm |
Seat Height | 665 mm |
Weight | 296 kg |
Explore more on Harley-Davidson Breakout 117
![Harley-Davidson Breakout 117 Harley-Davidson Breakout 117](https://images.91wheels.com/assets/b_images/main/models/profile/profile1714814805.jpg?width=210&q=60?width=240&q=60?w=640&q=60)
Don't miss out on Latest Offers!
Key Specifications of Breakout 117
Key | Specs Value |
---|---|
Displacement | 1923 cc |
Max Torque (nm@rpm) | 168 Nm @ 3500 rpm |
Max Power (bhp @ rpm) | 101.9 bhp @ 5020 rpm |
Weight | 296 kg |
Fuel Tank Size | 18.9 Litres |
Ad
Detailed Specifications of Harley-Davidson Breakout 117
Brakes, Suspension & Tyres
Braking System | Dual Channel ABS |
Calliper Type | Front 4 Piston Rear 2 Piston |
Front Disc Size | 300 |
Front Wheel Size | 21 |
Rear Suspension Preload Adjuster | Yes |
Rear Wheel Size | 18 |
Wheel Type | Alloy |
Front Suspension | Dual-bendinvalv4mtelescopiwitaluminufortriplclampsduaratspring |
Rear Suspension | Hidden& free piston& coil-over moNoshock; 43mm stroke; toolless hydraulic preload adjustment |
Front Tyre Size | 130/60 - B21 |
Rear Tyre Size | 240/40 - R18 |
Front Type | Disc |
Rear Disc/Drum Size | 292 mm |
Rear Type | Disc |
Tubeless Tyres | Yes |
Comfort & Convenience
Front Storage Box | No |
Low Battery Indicator | Yes |
Low Oil Indicator | Yes |
Pillion Backrest | No |
Pillion Footrest | Yes |
Service Reminder Indicator | Yes |
Under Seat Storage | No |
Distance to Empty Indicator | Yes |
Engine Kill Switch | Yes |
Luggage Space | No |
Side Stand Indicator | Yes |
Start Type | Self Start |
USB Charger Port | Yes |
Engine & Transmission
Gear Shifting Pattern | 1 Down 5 Up |
Engine Capacity | 1923 cc |
Engine Type | Milwaukee-Eight 117 |
No. of valves per cylinder | 4 |
Transmission Type | Chain Drive |
Bore x Stroke | 103.5 mm x 114.3 mm |
Configuration | 10.2:1 |
Fuelling | Fuel Injection |
Max Power | 101.9 bhp @ 5020 rpm |
Max Torque | 168 Nm @ 3500 rpm |
Mileage (Claimed) | 17.86 kmpl |
Number of Gears | 6 Speed |
Instrumentation
Touch Screen Display | No |
Fuel level guage | Yes |
Gear Indicator | Yes |
Tachometer | Digital |
Speedometer | Digital |
Odometer | Digital |
Safety
AHO (Automatic Headlight On) | Yes |
Hazard Warning Indicator | Yes |
Hazard Warning Switch | Yes |
Radial Tyres | Yes |
Pass Light | Yes |
Pillion Grabrail | Yes |
Turn Signal | LED |
ABS - Anti-lock braking system | Dual Channel ABS |
Brake Assist | Dual Channel ABS |
Slipper Clutch | Assist And Slipper Clutch |
Traction Control System | Yes |
Dimensions & Capacity
Length | 2370 mm |
Width | 950 mm |
Height | 1085 mm |
Wheelbase | 1695 mm |
Ground Clearance | 115 mm |
Fuel Tank Capacity | 18.9 Litres |
Engine Oil Capacity | 4.7 Litres |
Seat Height | 665 mm |
Unladden/Kerb Weight | 296 kg |
Exterior
Daytime Running Lights | Yes |
LED headlight | Yes |
Warranty
Basic Warranty | 2 Years or Unlimited km |
Body & Suspension
Frame Type | Mild Steel& Tubular Frame |
Ad
Breakout 117 Competitors Specifications
User Reviews
No Reviews FoundTop Harley-Davidson Bikes
Have More Questions about Harley-Davidson Breakout 117?
Get answers from our 91wheels experts
![ask a question ask a question](https://images.91wheels.com/images/sprite/ask_question_icon.jpg?w=128&q=65)
Ask 91Wheels Experts
Explore More Options
Harley-Davidson Breakout 117 FAQs
What is the fuel tank capacity of Harley-Davidson Breakout 117?
Fuel tank capacity of Harley-Davidson Breakout 117 is 18.9 Litres.
How much is the Engine Capacity of Harley-Davidson Breakout 117?
Engine Capacity of Harley-Davidson Breakout 117 is 1923 cc.
What is the seat height of Harley-Davidson Breakout 117?
Seat Height of Harley-Davidson Breakout 117 is 665 mm.
